Name: UT682D Wire Tracker/Tone and Probe
SKU: 28461
Availability: InStock

UT682D Wire Tracker/Tone and Probe

850,00 EGP

Specifications	Range		UT682D
Wire tracking features	Wire types		Telephone line\twisted-
			pair\electric wire
	Indication light for signal strength
	Live switchboard wire tracing
	Switchboard wire tracing distance
	Telephone lines tracking distance		≥3000m
	Unshielded cables tracking distance
	Shielded cables tracking distance
	Open and short circuit test
	Polarity indication for	DCV function, range:	√
	telephone lines	±(5V~52V)
	Telephone lines and LAN cables distinction	Jacks distinction	√
	Broken wire tracking		NO
	Transmitter output voltage		8V DC with a new battery
	Transmitter power supply	9V battery	√
	Receiver power supply	9V battery	√
	Max receiver standby current	~10mA	√
	Max receiver operating current	<40mA (AC, RMS)	√
Transmitter input voltage protection			60V DC
Operating environment	Operating temperature: 0~40℃; Storage temperature: -10~50℃
	Operating humidity: 20~75%RH; Storage humidity: 10~90%RH; Altitude: ≤2000m
General Characteristics
Product Color	Red and grey
Product net weight	UT682D: Transmitter-150g, Receiver-130g
Product size	UT682D: Transmitter-74mm x 68mm x 28mm, receiver-208mm x 47mm x 33mm
Standard accessories	9V battery x 2, RJ11 cable (UT682), RJ45 cable (UT682), RJ11 cable with alligator clips (UT682)
Standard individual packing	gift box (UT682D), English manual

Category: ALL

Description

UT682D wire tracker consists of a transmitter and a receiver, it is able to track ethernet/telephone/power cables without opening their insulation. UT682 can troubleshoot ethernet cables and is a recommended tool for debugging communication cables and audio/video cables.

Features

Telephone/ethernet/power cable tracking
DC level test, can check voltage level and polarity
Ethernet cable wiring sequence verification
Fast open/short circuit test
Volume adjustment
Headset connection for noisy environment
Dual measurement cycle mode
Low battery indication
